punQtum by Riedel Wireless Speaker Station

punQtum by Riedel Wireless Speaker Station

SKU:RIE-Q210-PW

Regular price $4,266.00
Regular price Sale price $4,266.00
Sale Sold out
PRICE EXCLUDES GST. THIS WILL BE ADDED AT CHECKOUT.

The Q210 PW – Speaker Station gives you full control in a cost-effective and easy-to-use package. punQtum Wireless can be connected to a punQtum network by using a Wi-Fi access point and the Q210 PW speaker station.

The station serves up to 4 connections to punQtum Wireless Apps and is equipped with 4 Channel communication and programmable buttons, allow muting all mics, make paging announcements or trigger logic outputs. Equipped with a network switch with 4 ports. Two of them are PoE powered to drive up to 4 wired beltpacks each

View full details

Capabilities and Functions

punQtum Q210 PW Speaker Station Features & Specifications

punQtum Q210 PW Speaker Station Product Features

- 4-channel partyline speaker station
- Compatibility with punQtum Wireless - up to 4 mobile devices
- Built-in loudspeaker
- Microphone and headset connector
- Rugged, Ethercon™ connectors
- Easy-to-read colour display
- Four configurable buttons for PA announcements, talk to all and GPO
- An audio replay of missed comms
- GPI inputs and outputs
- Analogue inputs/outputs (2x 4-wire ports + 2x inputs + 2x outputs)
- Built-in PoE switch to power up to 8 beltpacks
- 2 Public address output
- 2 Program signal inputs
- On- and Offline configuration software (Win/ Mac)

punQtum Q210 PW Speaker Station Technical Specifications

'- Power Source: 50 … 54 VDC
- PoE Power: 30W per PoE port
- Sampling Rate: 16 kHz
- Headset Connector: XLR 4pin male
- Connector Ethernet/LAN: 4x RJ-45 EtherCon
- Microphone Connector: 1/4“ jack with 7/16“ -20 UNF thread
- Built-in Speaker: 5 Watts
- Operating Temp: -10° to +50°C
- Operation Environment Humidity: 0 to 90% non-condensing
- Dimensions: 19“ 1HU: 100 x 433 x 44 mm
- Weight: 1.7 kg

**Headphone Output**

- Output impedance: 27 Ohm
- Output level: + 18.5 dBu (max.)
- Frequency response: 20Hz to 7kHz (+0/-1dB)
- Distortion @ 1kHz: <-73 dB (0.02%)
- Dynamic range (20kHz): 95 dB (A-weighted)

**Microphone Input**

- Bias Voltage: 5.4V (typ.)
- Full-scale input range: -53 … +4 dBu
- Distortion @ 1kHz: < -75 dB (0.02%) @ + 4dBu FS (min. gain), < -68 dB (0.04%) @ -30dBu FS, < -49 dB (0.35%) @ -53dBu FS (max. gain)
- Dynamic range: 92 dB (min. gain), 59 dB (max. gain)

**Analog Interface Outputs**

- Input Impedance: < 2 Ohm
- Input Level: + 18 dBu (max.)
- Frequency Response: 20Hz to 7kHz (+0/-0.25dB)
- Distortion @ 1kHz: <-80 dB (0.01%)
- Dynamic Range (20kHz): 98 dB (A-weighted)

**Analog Interface Inputs**

- Input Impedance: > 20 kOhm
- Input Level: + 18 dBu (max.)
- Frequency Response: 20Hz to 7kHz (+0/-0.25dB)
- Distortion @ 1kHz: <-80 dB (0.01%)
- Dynamic Range (20kHz): 90 dB (A-weighted)

**GPI Inputs**

- Input Connector: D-Sub 9 female
- Number of GPI Inputs: 4
- Input Type: Optocoupler input with current limiter
- Input Voltage: 5 … 50 VDC
- Input Current: 5 mA (typ.)

**GPI Outputs**

- Output Connector: D-Sub 9 male
- Number of GPI Outputs: 4
- Output Type: PhotoMOS Relay
- On Resistance: < 3 Ohm
- On Current: 200 mA (max.) – resettable PTC fuse 400 mA
- Maximum Voltage: 50 VDC / 35 VAC
