Matrox CIP-DSS ConvertIP Dual-channel SFP SDI-to-IP Transmitter/Receiver Matrox CIP-DSS ConvertIP Dual-channel SFP SDI-to-IP Transmitter/Receiver

Matrox CIP-DSS ConvertIP Dual-channel SFP SDI-to-IP Transmitter/Receiver

MAT-CIP-DSS
Contact us for Pricing
1 Remaining in Stock

    The Matrox ConvertIP DSS serves as a compact, independent device functioning as a transmitter and receiver for ST 2110 and IPMX protocols. With 12G-SDI, genlock, one RJ45, and two SFP28 ports integrated into a single unit, ConvertIP DSS accommodates compressed or uncompressed workflows up to 25G, ensuring an ultra-low latency experience. Power can be received via Ethernet through its RJ45 connection or through an optional power supply unit. Both power sources can be utilized simultaneously to ensure redundancy.

    CONTACT US for a demonstration or more information.

    Main Features

    • 12G-SDI I/O
    • Multi-network support
    • 2x SFP28 (10G & 25G network support)
    • 1x RJ45 (1G network support)
    • Transmit or receive IP signals from a single device
    • Boost monitoring capacity and resiliency using Daisy Chain Mode
    • Standardized Discovery and Routing – based on AMWA NMOS IS-04 and IS-05 specifications
    • Fanless design for quiet cooling
    • PTP-derived genlock output support
    • Genlock support for house sync input
    • Power redundancy through PoE+ and locking AC power connector (optional power supply cable sold separately) Compact form factor mounts easily to the back of a monitor
    • Web-based user interface for managing ConvertIP devices
    • Complimentary ConvertIP Manager Windows application for simple commission and deployment

    Specifications

    Connectivity

    • Video input:
      • TX mode: 1.5G, 3G, and 12G SDI
      • RX mode: No input
    • Video output:
      • TX mode: No output
      • RX mode: 1.5G, 3G, and 12G SDI
    • Video resolution: HD and 4K resolutions (including broadcast)
    • Genlock: Bi-Level genlock input support
    • VANC ancillary data processing: Yes
    • Audio input/output:
      • Up to 16 channels of audio embedded in SDI output signal
      • Unbalanced analog stereo input via 1/8″ (3.5mm) jack1
      • Line Level
    • Network connector:
      • 2x SFP28 cages for ST 2110 media and In-band control on LAN 1 and LAN 2
        • 10 GbE IEEE 802.3ae (10GBASE-SR/LR fiber module)
        • 25 GbE IEEE 802.3by (25GBASE-SR/CR/CR-S)
        • 25 GbE IEEE 802.3cc (25GBASE-LR)
      • LAN2 for redundancy mode only
      • Dedicated RJ45 management network interface for control only with PoE+ (100/1000 Mbps)
    • RS-232: Yes
    • Control and management: Matrox ConvertIP Command Center (web UI) + Matrox ConvertIP Manager (software application)

    Performance

    • Maximum video resolutions: 4096 x 2160 60p
    • Bit depth and color space:
      • YCbCr 4:2:2 10-bit
      • SDR/HDR

    Video and Audio Processing

    • Video scaling: High Quality multi-tap 10-bit Up/Down Scaler
    • Video deinterlacing: Yes
    • Color space conversion: Yes
    • HDCP support: Not applicable

    Encoding Formats

    • Video:
      • Uncompressed
        • HD 3 Gbps and 4K 12 Gbps
      • Default compressed bitrates: 200 Mbps for HD content, 820 Mbps for 4K content
        • Colibri codec included - 4:2:2 10-bit YUV and 4:4:4 8-bit RGB. 100 to 2000 Mbps
        • JPEG-XS codec upgrade required - 4:2:2 10-bit YUV and 4:4:4 8-bit RGB. 100 to 2000 Mbps
    • Audio: Uncompressed PCM (~1 Mbps/ch)
    • Latency: Less than a 1/4 frame (<4 ms)

    Network

    • Network standard: RJ45 providing 1 GbE or 2.5 GbE Base-T Ethernet
    • IP addressing:
      • IPv4
      • IPv61
      • DHCP (default) and static IP
    • Supported protocols
      • SMPTE ST 2110 (-10, -20, -21, -22, -30, -401)
      • SMPTE 2059 (-1, -2)
      • IPMX ready
    • Redundancy: Yes (ST 2022-7)
    • Command and control: HTTPS over TC
    • Discovery, registration and control: NMOS discovery and control according to standards IS-04 v 1.2 and 1.3 and IS-05 1.0 and 1.1
    • PoE+: Yes (IEEE 802.3 at Type 2)

    Physical

    • Dimensions: 181 (D) x 191 (W) x 36 (H) mm
    • Weight: 770g
    • Cooling: Fanless
    • Power
      • Device: Input: 12 volts, max 18 Watts
      • PoE+
      • Optional PSU (sold separately)
        • Line Voltage: 100-240 V a.c., 0.5A
        • Frequency: 50-60 Hz
        • Input: IEC320-C14
        • Output: DIN4 locking power connector

    Hardware and Software

    • Hardware included: ConvertIP DSS appliance
    • Optional hardware: ConductIP NMOS-based routing solution (Part #: CDCTIP-MRA)
    • Accessories (sold separately)
      • ConvertIP power supply unit (Part #: EPS40WKIT-NA, EPS40WKIT-EU, EPS40WKIT-UK, EPS40WKIT-AU, EPS40W-10PK)4
      • Rackmount kit (Part #: RMK-19TR-A)5
      • Angled bracket kit (Part #: RMK-6BRKT-A)
      • NRG redundant power supply unit (Part #: NRG-5-1DB or NRG-5-2DB)
    • Optional software:
      • JPEG-XS codec license
      • Crestron Module to expand existing controlled environments

    Environmental

    • Operating conditions:
      • Temperature: 0 to 45 degrees Celsius
      • Altitude: 650 hPa (3,580 m) to 1,013 hPa (0 m)
      • Humidity: 20% to 80% non-condensing
    • Storage conditions:
      • Temperature: -40 to 70 degrees Celsius
      • Altitude: 192 hPa (12,000 m) to 1,020 hPa (-50 m)
      • Humidity: 5% to 95% non-condensing

    General

    • EMC/EMI device class: Class A
    • EMC/EMI compliance: RCM (Aus/NZ), CE (EU), FCC (USA), ICES-003 (Canada), KC (Korea)
    • Environmental compliance: China RoHS, EU RoHS, REACH
    • Warranty: Three-year limited warranty with free online or telephone support
