Kenwood NXR-1700/NXR-1800 Repeater

Kenwood NXR-1700/NXR-1800 Repeater

SKU:KEN-NXR-1700

Regular price $3,960.02
Regular price Sale price $3,960.02
Sale Sold out
PRICE EXCLUDES GST. THIS WILL BE ADDED AT CHECKOUT.

Frequency

The Kenwood NXR-1700/1800 Repeater Radio is a compact, multi-mode conventional repeater. As a robust successor to the highly regarded DMR and NXDN repeaters such as the TKR-D710/D810 and NXR-710/810, this repeater delivers outstanding features and performance. The digital protocol can be selected at the time of purchase, allowing for configuration as either DMR or NXDN, with the option to maintain the factory default FM analog setting.

The large OLED display on the front panel shows important information such as MAC/IP Address, RSSI/TX Power Setting Icon, Channel Number/Name, RF Frequency, and Firmware/ESN/License/Error statuses.

The NXR-1700/1800 offers a significantly reduced volumetric capacity, requiring only a quarter of the rack space compared to older models like the NXR-710/810 and TKR-D710/D810, and occupying just half the space of other 1U repeaters.

View full details

Capabilities and Functions

Kenwood NXR-1700/1800 Repeater Features & Specifications

Kenwood NXR-1700/1800 Repeater Product Features

'- Digital Protocol: DMR Tier II / NXDN
- 50W (VHF) @ 50 % Duty
- Large 1.71-inch OLED with Icons and Numeric Displays
- Hot Standby System Redundancy
- IP Remote Management (Monitor / Control
- Voting Repeater + Up to 15
- Digital Multi-site Conventional IP Network

Kenwood NXR-1700/1800 Repeater Technical Specifications

'- Frequency Range: UHF 400-470MHz, UHF 450-520MHz
- Channel Capacity: 32
- Channel Spacing
- Analogue: 25 */ 12.5 kHz
- Digital: 12.5 / 6.25 kHz
- PLL Channel Step: 6.25 / 5 / 3.125 kHz
- Frequency Stability: ± 0.5 ppm
- Power Supply: 10.8 - 15.6 V DC
- Current Drain
- Standby: 0.7 A
- Transmitting: 12.0 A (Max. power), 9.0 A (25 W)
- Operating Temperature: -30 ºC to +60 ºC
- Antenna Impedance: 50 Ω
- Dimensions
- Incl Projections: (214.5 x 44.0 x 242.9 mm)
- Excl Projections: (208.5 x 44.0 x 211.5 mm)
- Weight: 1.9kg
- FCC ID: K44513200 (450-520MHz), K44513201 (400-470MHz)
- ISED Cert No: 282F-513201 (400-470MHz)

**Receiver**

- Sensitivity:
- DMR (5% BER): 0.22 μV
- DMR (1% BER): 0.22 μV
- NXDN (3% BER) 12.5 / 6.25 kHz: 0.25 / 0.20 μV
- Analogue (12dB SINAD): 0.25 μV
- Selectivity:
- Analogue 25 / 12.5 kHz (TIA603): 80 / 74 dB
- Analogue 25 / 12.5 kHz (TIA603E): 80 / 50 dB
- FM Hum & Noise: 55 / 50 dB
- Intermodulation: 80 dB
- Spurious Rejection: 90 dB

**Transmitter**

- RF Output Power: 40 - 1W (40W @ 50% duty, 25W @ 100% duty)
- Spurious Emission: -80dB
- FM Hum & Noise: 55 / 50 dB
- Auto Distortion: 1%
- Digital Protocol (DMR): ETSI TS 102 361-1, -2, -3
- Emission Designator: 16K0F3E, 11K0F3E, 7K60FXD, 7K60F7D, 7K60FXE, 7K60F7E, 7K60FXW, 7K60F7W,
8K30F1E, 8K30F1D, 8K30F7W, 4K00F1E, 4K00F1D, 4K00F7W, 4K00F2D
