ICOM Active Antenna for Building
ICOM Active Antenna for Building
SKU:ICO-AH41
Couldn't load pickup availability
The ICOM AH-41 Antenna is a cutting-edge solution tailored for seamless indoor satellite communications. It efficiently covers both Iridium® satellite frequencies and GNSS L1 band frequencies. For optimal installation, users can utilize the optional OPC-2462 coaxial cable measuring 59 m (193.5 ft) or opt for a user-supplied coaxial cable up to a length of 169 m (554.5 ft) to ensure a clear line-of-sight to the satellite. One of its standout features is the Power over Coaxial (PoC) technology, which allows the antenna to draw electrical power directly through the coaxial cable, reducing the need for additional power cabling. The antenna is also designed with separate TX and RX units, with the TX unit integrated with a Power Amplifier and the RX unit equipped with a Low Noise Amplifier (LNA) for enhanced signal reception. Built for durability, the main unit boasts IP67 protection, making it waterproof and dust-tight, ideal for outdoor installations.
Capabilities and Functions
ICOM AH41 Active Antenna Features & Specifications
ICOM AH41 Active Antenna Product Features
ICOM AH41 Active Antenna Technical Specifications
**Frequency range:**
- 1616.02–1626.48 MHz (TX unit/RX unit)
- 1575.42–1605.4 MHz (RX unit, GNSS L1 band)
**Antenna impedance:** 50 Ω nominal (N-J connector)
**Polarization:** Right-hand circular
**Operating temperature range:** –25°C to +55°C, –13°F to +131°F
**Current drain (approximate):**
- Less than 2.5 A (at relay)
- Less than 0.8 A (stand-by)
**Dimensions (W × H × D) (projections not included):**
- 310 × 326 × 89 mm (TX/RX units + bracket)
- 77 × 200 × 77 mm (each unit)
**Weight (approximate):** 1.6 kg, 3.5 lb
### TX UNIT
**Rated output power:** 37.7 dBm ± 1 dB (at 23.3 dBm input to TX unit)
**Spurious emissions:**
- 0.25 μW (≤ 1 GHz)
- 1.0 μW (> 1 GHz)
### RX UNIT
**Total gain:** 17 dB ±1.5 dB (at –80 dBm input to RX unit)
**Noise figure:** Less than 3.0 dB
**Spurious emissions:**
- 0.25 μW (≤ 1 GHz)
- 1.0 μW (> 1 GHz)
_All stated specifications are subject to change without notice or obligation._
**Applicable IP Rating**
**IP rating (AH-41 main unit):** IP67 (Waterproof and dust-tight)
